BENDIXKing KY 97A - Transmitter Board

B KY 96A, KY 97A
Rev 5, Apr 2003 MM 006-05674-0005.dwd Page 6-105
6.4.8 Transmitter Board
200-07540-0000 KY97A 14V 5W TX BD REV 4
200-07540-0001 KY96A 28V 5W TX BD REV 4
200-07540-0099 KY96A/97A COM TX BD REV AB
-----------------------------------------------------------------------------
SYMBOL PART NUMBER FIND NO DESCRIPTION UM -0000 -0001 -0099
-----------------------------------------------------------------------------
C401 113-05102-0000 CAP DC .001UF 500V EA . . 1.00
C402 097-00104-0036 CAP AL 47UF 25V EA . . 1.00
C403 113-05331-0000 CAP DC 330PF 500V EA . . 1.00
C404 113-03121-0000 CAP DC 120PF 500V EA . . 1.00
C405 113-05102-0000 CAP DC .001UF 500V EA . . 1.00
C406 111-00001-0001 CAP CR .1UF 50V EA . . 1.00
C407 096-06105-0052 CAP TN 1.0UF50V20% EA . . 1.00
C408 106-04331-0026 CAPCH330PFNPO/100V EA . . 1.00
C409 106-04331-0026 CAPCH330PFNPO/100V EA . . 1.00
C410 113-03151-0000 CAP DC 150PF 500V EA . . 1.00
C411 104-00001-0015 CAP SM 10PF 100V EA . . 1.00
C412 104-00001-0009 CAP SM 47PF 100V EA . . 1.00
C413 104-00001-0017 CAP SM 39PF 100V EA . . .50
C413 104-00001-0031 CAP SM 27PF 500V EA . . .50
C414 104-00001-0000 CAP SM 100PF 100V EA . . 1.00
C415 104-00001-0014 CAP SM 33PF 100V EA . . 1.00
C416 104-00001-0008 CAP SM 75PF 100V EA . . 1.00
C417 100-00003-0001 300PF 500V 5% CP EA . . 1.00
C418 102-00024-0010 CAP VAR 7-45PF N15 EA . . 1.00
C419 104-00001-0030 CAP SM 18PF 500V EA . . 1.00
C420 104-00001-0033 CAP SM 15PF 500V EA . . 1.00
C421 104-00001-0030 CAP SM 18PF 500V EA . . 1.00
C422 104-00001-0063 CAP SM 12PF 100V EA . . 1.00
C423 104-00001-0041 CAP SM 22PF 500V EA . . 1.00
C424 106-00074-0036 CAP PF 9.1 500VDC EA . . 1.00
C425 106-00074-0033 CAP PF 6.8 500VDC EA . . 1.00
C426 104-00001-0041 CAP SM 22PF 500V EA . . 1.00
C427 104-00001-0063 CAP SM 12PF 100V EA . . 1.00
C428 113-03121-0000 CAP DC 120PF 500V EA 1.00 . .
C428 113-05102-0000 CAP DC .001UF 500V EA . 1.00 .
C429 113-05331-0000 CAP DC 330PF 500V EA . . 1.00
C430 113-05102-0000 CAP DC .001UF 500V EA . . 1.00
C431 999-09999-0098 PLACE HOLDER RF . . .00
C432 999-09999-0098 PLACE HOLDER RF . . .00
C433 999-09999-0098 PLACE HOLDER RF . . .00
C434 999-09999-0098 PLACE HOLDER RF . . .00
C436 999-09999-0098 PLACE HOLDER RF . . .00
C437 104-00001-0045 CAP SM 43PF 100V EA . . 1.00
C438 113-03121-0000 CAP DC 120PF 500V EA . . 1.00
C439 113-05331-0000 CAP DC 330PF 500V EA . . 1.00
C440 104-00001-0031 CAP SM 27PF 500V EA . . 1.00
C441 111-00001-0021 CAP CR .0068UF 100 EA . . 1.00
C442 104-00001-0002 CAP SM 91PF 100V EA . . 1.00
C443 106-04331-0026 CAPCH330PFNPO/100V EA . . 1.00
C444 106-04331-0026 CAPCH330PFNPO/100V EA . . 1.00
C445 113-05102-0000 CAP DC .001UF 500V EA 1.00 . .
C445 999-09999-0098 PLACE HOLDER RF . .00 .
C446 113-05331-0000 CAP DC 330PF 500V EA . . 1.00
C447 104-00001-0002 CAP SM 91PF 100V EA . . 1.00
C448 104-00001-0009 CAP SM 47PF 100V EA . . 1.00
C449 113-03121-0000 CAP DC 120PF 500V EA . . 1.00
CR401 007-06099-0000 DIO UM9401 EA . . 1.00
CR402 007-06099-0000 DIO UM9401 EA . . 1.00
CR403 007-06228-0000 RF SWITCHING DIODE EA . . 1.00
L401 013-00006-0001 FERR BEAD EA . . 1.00
L402 013-00006-0001 FERR BEAD EA . . 1.00
L403 013-00006-0001 FERR BEAD EA . . 1.00
