BENDIXKing KY 97A - Bushing

B KY 96A, KY 97A
Rev 5, Apr 2003 MM 006-05674-0005.dwd Page 6-19
064-01052-0031 96A 50K SEL 136975 REV AB
064-01052-0050 96A 25KHZ W/AUDAMP REV AB
064-01052-0051 96A 50KHZ W/AUDAMP REV AB
064-01052-0099 COMMOM BOM REV AD
------------------------------------------------------------------------------------
SYMBOL PART NUMBER FIND NO DESCRIPTION UM -0031 -0050 -0051 -0099
------------------------------------------------------------------------------------
I108 120-03026-0000 IC MC7805CT EA . . . 1.00
Q113 007-00930-0000 XSTR S PNPMJE15029 EA . . . 1.00
Q122 007-00930-0000 XSTR S PNPMJE15029 EA . . . 1.00
REF1 300-04268-0000 KY96A COMM TRANSC RF . . . .00
REF100 000-00601-0002 PRODUCT STRUCTURE RF . . . .00
012-01005-0002 TAPE MYLAR .500 W IN . . . .50
012-01127-0000 TAG COVER EA . . . 4.00
013-00006-0001 FERR BEAD EA . . . 4.00
016-01008-0004 GLYPTAL 7526 BL AR . . . 1.00
016-01015-0000 IND ADH 3M 4475 AR . . . 1.00
016-01071-0000 DC RTV 3140 AR . . . 1.00
025-00005-0002 WIRE 18 RED IN . . . 10.75
025-00005-0012 WIRE 18 RD/WH IN . . . 9.00
025-00018-0022 WIRE 26 RED IN . . . 2.00
025-00018-0024 WIRE 26 RD/YL IN . . . 11.00
025-00018-0092 WIRE 26 WH/RD IN . . . 10.50
025-00018-0096 WIRE 26 WH/BU IN . . . 10.50
025-05012-0000 WIRE 2C SHD WHTBLK IN . . . 9.50
030-02229-0011 RGT ANG HDR 3P EA . . . 1.00
030-02229-0013 RGT ANG HDR 7P EA . . . 1.00
030-02229-0014 RGT ANG HDR 6P EA . . . 1.00
035-01007-0020 CONN CVR NAS820-8 EA . . . 1.00
035-01361-0020 PROTECTIVE COVER EA . . . 1.00
047-04811-0001 COVER XMTR W/F EA . . . 1.00
047-08494-0501 TOP COVER ASSEMBLY EA 1.00 . . .
047-08495-0002 COVER, BOTTOM EA . . . 1.00
047-08512-0004 MOUNTING RACK EA . . . 1.00
047-12516-0501 TOP COVER ASSY EA . 1.00 1.00 .
057-01540-0000 WARNING HV TAG EA . . . 1.00
057-02203-1031 S/N TAG FLVR BLK EA 1.00 . . .
057-02203-1050 S/N TAG FLVR BLK EA . 1.00 . .
057-02203-1051 S/N TAG FLVR BLK EA . . 1.00 .
057-02312-0001 DECAL EA 1.00 . 1.00 .
057-02337-0000 PRTCTV CVR DECAL EA . . . 1.00
057-03451-0001 S/N TAG KY96A EA . . . 1.00
057-03511-0001 DECAL, CAUTION EA . . . 1.00
064-01052-0099 COMMOM BOM EA 1.00 1.00 1.00 .
073-00808-0003 KNOB VOLUME EA . . . 1.00
088-00838-0006 PUSH BUTTON EA . . . 1.00
088-02269-0003 BEZEL LCD EA . . . 1.00
088-02270-0000 PUSH BUTTON, RND EA . . . 1.00
088-02271-0000 LIGHTING SHAFT EA . . . 1.00
089-05434-0003 SCR FHP 3-48X3/16 EA . . . 9.00
089-05434-0004 SCR FHP 3-48X1/4 EA . . . 8.00
089-05874-0005 SCR PHP 2-56X5/16 EA . . . 1.00
089-05899-0003 SCR PHP 2-56X3/16 EA . . . 1.00
089-05901-0004 SCR PHP 3-48X1/4 EA . . . 7.00
089-05903-0004 SCR PHP 4-40X1/4 EA . . . 3.00
089-05925-0004 SCR BHP 3-48X1/4 EA . . . 5.00
089-06004-0003 SCR FHP 2-56X3/16 EA . 5.00 5.00 .
089-06298-0004 SCR FHP 3-48X1/4 EA . . . 2.00
089-06342-0004 SCR PHP 3-48X1/4 EA . . . 4.00
090-00991-0000 PROTECTIVE CLOSURE EA . . . 1.00
091-00109-0000 CABLE TIE EA . . . 2.00
091-00156-0000 BUSHING EA . . . 3.00
091-00286-0002 INSUL XSTR .687 EA . . . 2.00
150-00049-0010 SHRINK TUBING WHT IN . . . 1.25
150-00060-0001 SPIROBAND IN . . . 5.25
150-00072-0004 SLDR SLEEVE .62 EA . . . 2.00
