B KY 96A, KY 97A
Rev 5, Apr 2003 MM 006-05674-0005.dwd Page 6-135
6.4.9 Audio Amplifier Board
200-07797-0000 AUDIO AMP BOARD REV 9
---------------------------------------------------------------
SYMBOL PART NUMBER FIND NO DESCRIPTION UM -0000
---------------------------------------------------------------
C1201 106-04121-0026 CAPCH120PFNPO/100V EA 1.00
C1202 106-04121-0026 CAPCH120PFNPO/100V EA 1.00
C1203 106-04121-0026 CAPCH120PFNPO/100V EA 1.00
C1204 106-04121-0026 CAPCH120PFNPO/100V EA 1.00
C1205 106-04121-0026 CAPCH120PFNPO/100V EA 1.00
C1206 097-00108-0015 CAP EL 10UF 35V EA 1.00
C1207 106-04103-0057 CAP CH 10KX7R/100V EA 1.00
C1208 999-09999-0096 RESERVED RF .00
C1209 999-09999-0096 RESERVED RF .00
C1210 097-00108-0021 CAP EL 1.OUF 50V EA 1.00
C1211 097-00108-0007 CAP EL 10UF 16V EA 1.00
C1212 097-00108-0013 CAP EL 33UF EA 1.00
C1213 097-00108-0021 CAP EL 1.OUF 50V EA 1.00
C1214 106-04471-0026 CH 470PF NPO/100V EA 1.00
C1215 097-00108-0014 CAP EL 4.7UF 35V EA 1.00
C1216 097-00108-0015 CAP EL 10UF 35V EA 1.00
C1217 097-00108-0013 CAP EL 33UF EA 1.00
C1218 106-04471-0026 CH 470PF NPO/100V EA 1.00
C1219 106-04103-0057 CAP CH 10KX7R/100V EA 1.00
C1220 106-04222-0057 CAPCH2200PFX7R/100 EA 1.00
C1221 106-04102-0026 CH 1KPF NPO/100V EA 1.00
C1222 097-00108-0007 CAP EL 10UF 16V EA 1.00
C1223 097-00108-0008 CAP EL 22UF EA 1.00
C1224 097-00108-0008 CAP EL 22UF EA 1.00
C1225 097-00149-0002 470UF 50V EL CAP EA 1.00
C1226 999-09999-0098 PLACE HOLDER RF .00
C1227 106-04103-0057 CAP CH 10KX7R/100V EA 1.00
C1228 106-04103-0057 CAP CH 10KX7R/100V EA 1.00
CR1201 007-05117-0015 DIO Z 13V SOT EA 1.00
CR1202 007-06222-0000 DIO DAN202K EA 1.00
CR1203 007-06033-0000 DIO G 1N270 EA 1.00
CR1204 007-06223-0000 DIO DUAL SWITCHING EA 1.00
CR1205 007-06222-0000 DIO DAN202K EA 1.00
CR1206 007-06222-0000 DIO DAN202K EA 1.00
F1201 036-00057-0008 FUSE 275 125V 3A EA 1.00
I1201 120-03053-0009 LM358D DUAL OP AMP EA 1.00
P1201 155-02499-0000 AUDIO CABLE ASSY EA 1.00
Q1201 007-00467-0000 XSTR S NPN MMBTA06 EA 1.00
Q1202 007-00535-0000 XSTR JFET MMBF4393 EA 1.00
Q1203 007-00187-0002 XSTR SOT-23 2N5089 EA 1.00
Q1204 007-00187-0002 XSTR SOT-23 2N5089 EA 1.00
Q1205 007-00078-0001 XSTR S NPN 2N3417 EA 1.00
Q1206 007-00238-0000 XSTR S PNP FPN4917 EA 1.00
Q1207 007-00930-0000 XSTR S PNPMJE15029 EA 1.00
Q1208 007-00525-0000 XSTR PWR MJE15028 EA 1.00
R1201 139-05110-0000 RES CH 511 EW 1% EA 1.00
R1202 139-05110-0000 RES CH 511 EW 1% EA 1.00
R1203 139-05110-0000 RES CH 511 EW 1% EA 1.00
R1204 139-01622-0000 RES CH 16.2K EW 1% EA 1.00
R1205 139-01622-0000 RES CH 16.2K EW 1% EA 1.00
R1206 139-01622-0000 RES CH 16.2K EW 1% EA 1.00
R1207 139-02001-0000 RES CHIP 2K EW 1% EA 1.00
R1208 999-09999-0096 RESERVED RF .00
R1209 130-05000-0025 RES CHIP 0 EW CJ EA 1.00
R1210 139-01301-0000 RES CH 1.30K EW 1% EA 1.00
R1211 139-01003-0000 RES CHIP 100KEW1% EA 1.00
R1212 139-09092-0000 RES CHIP 90.9KEW1% EA 1.00
R1213 139-05110-0000 RES CH 511 EW 1% EA 1.00
R1214 139-05112-0000 RES CHIP 51.1K 1% EA 1.00
