BENDIXKing KY 97A - Page 151

B KY 96A, KY 97A
Rev 5, Apr 2003 MM 006-05674-0005.dwd Page 6-157
------------------------------------------------------------------------------------
SYMBOL PART NUMBER FIND NO DESCRIPTION UM -0000 -0001 -0002 -0099
------------------------------------------------------------------------------------
R281 139-02210-0000 RES CH 221 EW 1% EA . . . 1.00
R282 139-01001-0000 RES CHIP 1K EW 1% EA . . . 1.00
R283 139-01002-0000 RES CHIP 10K EW 1% EA . . . 1.00
R284 139-03321-0000 RES CHIP 3.32K EW EA . . . 1.00
R286 139-04753-0000 RES CH 475K EW 1% EA . . . 1.00
R287 139-01502-0000 RES CHIP 15K EW 1% EA . . . 1.00
R288 139-01000-0000 RES CHIP 100 EW 1% EA . . . 1.00
R289 139-05620-0000 RES CH 562 EW 1% EA . . . 1.00
R290 139-01000-0000 RES CHIP 100 EW 1% EA . . . 1.00
R291 139-01000-0000 RES CHIP 100 EW 1% EA . . . 1.00
R292 139-01000-0000 RES CHIP 100 EW 1% EA . . . 1.00
R293 139-04752-0000 RES CH 47.5K EW 1% EA . . . 1.00
R294 139-04752-0000 RES CH 47.5K EW 1% EA . . . 1.00
R295 139-01001-0000 RES CHIP 1K EW 1% EA . . . 1.00
R296 130-05000-0025 RES CHIP 0 EW CJ EA . . . 1.00
R297 139-01001-0000 RES CHIP 1K EW 1% EA . . . 1.00
R298 139-04750-0000 RES CH 475 EW 1% EA . . . 1.00
R299 139-02210-0000 RES CH 221 EW 1% EA . . . 1.00
REF1 300-07799-0000 14V MAIN BOARD KY RF .00 . .00 .
REF1 300-07799-0001 28V MAIN BOARD K RF . .00 . .
REF2 002-07799-0000 KY96A/97A LCD MAIN RF . . . .00
T101 019-08079-0000 XFMR IF EA . . . 1.00
T102 019-08080-0000 XFMR IF 15PF EA . . . 1.00
T103 019-08102-0000 XFMR IF 27PF EA . . . 1.00
T104 019-08103-0000 XFMR IF EA . . . 1.00
T105 019-02328-0081 3.5 TURN CT EA . . . 1.00
T106 999-09999-0098 PLACE HOLDER RF . . . .00
T107 019-05083-0000 XFMR AUD EA . . . 1.00
T108 019-05084-0001 XFMR MOD 900T EA . . . 1.00
T109 999-09999-0098 PLACE HOLDER RF . . . .00
T110 999-09999-0098 PLACE HOLDER RF . . . .00
TP101 008-00096-0001 TERMINAL TEST PNT EA . . . 1.00
TP102 008-00096-0001 TERMINAL TEST PNT EA . . . 1.00
TP104 008-00096-0001 TERMINAL TEST PNT EA . . . 1.00
TP105 008-00096-0001 TERMINAL TEST PNT EA . . . 1.00
TP106 008-00096-0001 TERMINAL TEST PNT EA . . . 1.00
TP107 008-00096-0001 TERMINAL TEST PNT EA . . . 1.00
TP108 008-00096-0001 TERMINAL TEST PNT EA . . . 1.00
TP109 008-00096-0001 TERMINAL TEST PNT EA . . . 1.00
TP110 008-00096-0001 TERMINAL TEST PNT EA . . . 1.00
TP112 008-00096-0001 TERMINAL TEST PNT EA . . . 1.00
TP115 008-00096-0001 TERMINAL TEST PNT EA . . . 1.00
Y101 044-00272-0001 3.975 MHZ .001% EA . . . 1.00
009-07799-0000 PC BD MAIN EA . . . 1.00
012-01174-0000 INSULATOR EA . . . 5.00
016-01040-0000 COATING TYPE AR AR . . . 1.00
016-01082-0000 DC RTV 3145 AR . . . 1.00
025-00005-0002 WIRE 18 RED IN . . . 1.40
026-00004-0000 WIRE, CU, 20AWG, T IN 1.25 . 1.25 6.40
026-00013-0000 WIRE, COAX, RG-178 IN . . . 4.75
030-02174-0001 PIN CONT EA . . . 2.00
030-02174-0004 PIN CONTACT EA . . . 9.00
047-08202-0001 FENCE VCO EA . . . 1.00
047-08203-0001 FENCE PRESELECT/IF EA . . . 1.00
047-08208-0001 COVER VCO EA . . . 1.00
047-08209-0001 COVER PRESELECT/IF EA . . . 1.00
047-08476-0002 SHIELD VCO W/INS EA . . . 1.00
047-08477-0002 SHIELD PRESELW/INS EA . . . 1.00
047-08550-0002 GERMAN SHIELD EA . . . 1.00
089-06004-0003 SCR FHP 2-56X3/16 EA . . . 3.00
090-00213-0000 FUSE CLIP 1/4 IN. EA . . . 2.00
091-00025-0000 WSHR XSTR INSUL EA . . . 1.00
150-00003-0010 TUBING TFLN 24AWG IN . . . 1.08
