B KY 96A, KY 97A
Rev 5, Apr 2003 MM 006-05674-0005.dwd Page 5-7
After 2 minutes continuous key:
NOTE: Units with Mic-key Disable will shut down transmitter after 2 minutes. To ex-
tend transmit time re-key transmitter.
118.00 MHz ______ 1.25 watts Min. 13.75 V units
______ 1.25 watts Min. 27.5 V units
126.97 MHz ______ 1.25 watts Min. 13.75 V units
______ 1.25 watts Min. 27.5 V units
135.97 MHz ______ 1.25 watts Min. 13.75 V units
______ 1.25 watts Min. 27.5 V units
Low Voltage:
With a low line voltage input the following values should be observed:
22 Vdc for 27.5 V units
11 Vdc for 13.75 V units
118.00 MHz ______ 1.25 watts Min. 13.75 V units
______ 1.25 watts Min. 27.5 V units
126.97 MHz ______ 1.25 watts Min. 13.75 V units
______ 1.25 watts Min. 27.5 V units
135.97 MHz ______ 1.25 watts Min. 13.75 V units
______ 1.25 watts Min. 27.5 V units
5.3.3.B. Modulation Capability:
Input a standard modulator test signal into the microphone audio. Using the
linear detector, measure the Tx modulation.
5.3.3.B.1 118.000 MHz ______ NLT 70%
126.97 MHz ______ NLT 70%
135.97 MHz ______ NLT 70%
5.3.3.B.2 Carrier Noise Level:
Modulate the carrier with 70% at 1000 Hz.
Noise on the carrier with modulation removed shall be NLT:
118.00 MHz ___ 40dB 126.97 MHz ___ 40dB 135.95 MHz ___ 40dB
5.3.3.B.3 Demodulated Audio Distortion (Optional):
350 Hz = ___ 15% Max 1 kHz = ___ 15% Max 2.5 kHz = ___ 15% Max
(This is an optional test that requires a distortion analyzer).
5.3.3.B.4 Sidetone Audio Response:
