8300-088 AeroCruze 110 Installation Manual
Rev 1 Page 10
© Honeywell International Inc. Do not copy without express permission of Honeywell.
P101
Pin
Function Notes
J101 Pin 20 Pin 21
Standard J201-4 J201-5 Servo CCW (counter-
clockwise) RIGHT
Reversed J201-5 J201-4 Servo CW (clockwise)
RIGHT
24 TCB-A Unused at this time, for future
expansion.
25 TCB-B
