BENDIXKing XCRUZE 110 - Garmin G3 X Connections; Installation Support; Technical Support Contact Information

_____________________________________________________________________________________
8300-088 AeroCruze 110 Installation Manual
Rev 1 Page 20
© Honeywell International Inc. Do not copy without express permission of Honeywell.
Select the drop down menu under Serial Data Format. Choose one of the formats that outputs NMEA
Out. There are three options:
-Aviation In/NMEA & VHF Out is 9600 baud
-GTX TIS-A In/NMEA & VHF Out is 9600 baud
-NMEA Out is 4800 baud
Be sure to match the autopilot baud rate setting to the correct one.
9.18 Garmin Aera 500-510-550-560
Table 9-9 Garmin G3X Connections
Garmin G3X connections to TruTrak autopilot
P3701 (GDU 37X) Signal Name
(Garmin)
Signal Name
(TruTrak)
P101 on
xCruze 110 AP
48 GPS RS 232 OUT 1 Primary Serial Input 17
47 GPS RS 232 IN 1 Serial Output 7
P731 (GSU 73) if
equipped
P101 on
xCruze 110 AP
20 GPS ARINC 429 OUT A ARINC-A 14
21 GPS ARINC 429 OUT B ARINC-B 15
P292 (GAD 29) if
equipped
P101 on
xCruze 110 AP
18 GPS ARINC 429 OUT A ARINC-A 14
6 GPS ARINC 429 OUT B ARINC-B 15
Enter config mode on G3X PFD by holding left softkey while power is applied. Use knob to select COMM
tab. Select RS232 channel 1 and set to INTEGRATED AUTOPILOT.
Select ARINC channel 1 output. Set output to AUTOPILOT.
Set the autopilot baud rate to 9600.
10 INSTALLATION SUPPORT
For Installation Support Please Contact
Technical Support: techsupport@bendixking.com
US and Canada: 1-855-250-7027
Worldwide: 1-505-903-6148
https://www.bendixking.com/en/contact-us
