BENDIXKing XCRUZE 110 - UPSAT GX-50;60;65 Configuration

_____________________________________________________________________________________
8300-088 AeroCruze 110 Installation Manual
Rev 1 Page 17
© Honeywell International Inc. Do not copy without express permission of Honeywell.
Power 430/530 up and turn it on while holding down the ENT key. Release the ENT key when the display
activates. After the data base pages, the first page displayed is the MAIN ARINC 429 CONFIG page. While
in Configuration mode, pages can be selected by ensuring the cursor is off and rotating the small right
knob. To change data on the displayed Configuration Page, press the small right knob (CRSR) to turn on
the cursor. Turn the large right knob to change between data fields. Turn the large or small right knob to
change a field that the cursor is on. Once you have made the desired selection, press the ENT key to
accept the entry. The second startup page will test the RS 232 and ARINC inputs on the ground, a good
RS 232 connection will display GPS NAV and the asterisk, ARINC will display GPSS and move the stick
right and left.
With the MAIN ARINC 429 CONFIG page displayed, on the row labeled OUT, select SPEED  Low
and DATA 429 GAMA. In the VNAV row ENABLE LABELS.
Advance to the MAIN RS232 CONFIG page.
On the row labeled CHNL1, select OUTPUT  Aviation.
Note that for the Garmin units, the autopilot will need to be set for 9600 baud.
9.12 UPSAT GX-50/60/65
Table 9-3 UPSAT GX-50/60/65 connections
UPSAT GX-50/60/65 connections to TruTrak autopilot
37-Pin Connector
on UPSAT
GX-50/60/65
Signal Name
(UPSAT)
Signal Name
(TruTrak)
P101 on
xCruze 110 AP
5
or
22
Use pin 5 – TxD1 – if GX has no GPSS Primary Serial Input
17
Power the GX-50/60/65 up and turn it on while holding down the leftmost and rightmost “smart keys.”
Rotate the LARGE knob to the Serial Interface Configuration “CH RX TX” page. Press SEL (the selection
fields will start flashing), rotate the LARGE knob to select the port, rotate the SMALL knob to select the
desired configurations, and then press ENT when complete.
If both the GX unit AND the DigiFlight unit have GPSS capability, select “GPSS” for CH 2, TX column,
and wire pin 17 on the DigiFlight IIVSG to pin 22 of the GX unit Otherwise select “MOVING MAP” For
CH 1, TX column and wire pin 17 on the DigiFlight II / IIVS to pin 5 of the GX unit
To restore the GX-50/60/65 to normal operation, switch its power off, and then back on.
Note that for the GX-50/60/65 units, the autopilot will need to be set for 9600 baud.
