8300-088 AeroCruze 110 Installation Manual
Rev 1 Page 18
© Honeywell International Inc. Do not copy without express permission of Honeywell.
9.13 Garmin AT GNS480
Table 9-4 Garmin 430 and 530 Connections
Garmin AT GNS480 connections to autopilot
P1 on GNS480 Signal Name (Garmin AT) Signal Name (TruTrak) P101 on
xCruze 110 AP
22 RS232 TxD2 Primary Serial Input 17
P5 on GNS480 Signal Name (Garmin AT) Signal Name (TruTrak) P101 on
xCruze 110 AP
4 429 OUT 1A ARINC-A 14
24 429 OUT 1B ARINC-B 15
Power 480 up and select the 1, 4, MENU/ ENTER keys immediately after the GNS 480 initialization is
complete. After restart, the first page displayed is the SETUP page. Select the SERIAL PORTS with the
button next to it. Press the small knob to enter the edit mode and move to the TX column for the
channel that you have connected the serial wire to (channel 2). Select MAPCOM and 9600. Press the
small inner knob again to save. Then press the BACK to go back to the Setup page.
Select the ARINC PORTS SETUP. With the MAIN ARINC 429 CONFIG page displayed, on the row labeled
Channel 1 OUT, select and DATA ARINC 429, SPEED  Low.
Serial output baud rate should be set to 9600 on the GNS480. Set the TruTrak baud rate to 9600.
9.14 KMD 150
Power the KMD 150 up and turn it full bright. Press the MENU button then the SETUP button then the
INST & DIAGS button then the DATA IN/OUT. Change the DATA OUT PUT to NEMA 0183 the manual
states the Baud rate is 9600. The output pin is pin 11 and connects to the Primary Serial input on the
auto pilot controller.
You will need to match 9600 Baud rate in the auto pilot.
Table 9-5 KMD 150 connections
KMD 150 connections to TruTrak autopilot
Signal Name Signal Name P101 on
xCruze 110AP
(AV NAV) Primary Serial Input 17
9.15 Garmin GTN-650
Table 9-6 Garmin GTN-650 Connections
Garmin GTN-650 connections to autopilot
P1001 Signal Name
(Garmin)
Signal Name
(TruTrak)
P101 on
xCruze 110 AP
8 GPS RS 232 OUT 1 Primary Serial Input 17
10 GPS ARINC 429 OUT A ARINC-A 14
29 GPS ARINC 429 OUT B ARINC-B 15
