Autostacker™ Parking Lift 45 P/N 5900002 — Rev. D — August 2019
Lowering a Vehicle
This section describes how to get a Vehicle off of the Autostacker Platform.
To lower a Vehicle:
1. Check the items listed in Preparing to Raise or Lower a Vehicle.
If you find any issues, resolve them before lowering the Vehicle.
2. At the Console, insert your key and turn it to On.
3. Press and hold the Up button to raise the Lift off of the Safety Lock.
The Lock Hood and Lock Cam move nearly to
the next Lock Block in order to disengage
completely from the Safety Lock Block it was
secured on.
4. Once disengaged from the Lock Block, the Lock Cam will be facing down, as shown above.
Press and hold the Down button.
5. When the Autostacker Platform is resting on the ground, release the Down button.
6. Carefully drive the Vehicle off the Autostacker Platform.
7. Turn the key on the Console to Off, then remove it.
