BendPak Autostacker PL-6SR User Manual

Autostacker™ Parking Lift 7 P/N 5900002 — Rev. D — August 2019
Specifications
Specifications PL-6SR PL-6SRX
Lifting capacity 6,000 lbs. / 2,722 kg
A Total width 103" (8.6 feet) / 2,620 mm 111" (9.3 feet) / 2.815 mm
B Platform width 83.75" (7 feet) / 2,127 mm 91.75" (7.7 feet) / 2,331 mm
C Drive-thru width 83" (7 feet) / 2,112 mm 90.75" (7.7 feet) / 2,305 mm
D Overall length 143" (12 feet) / 3640 mm
E Platform plus ramp 143" (12 feet) / 3,632 mm
Platform only 129" (10.7 feet) / 3,274 mm
Maximum wheelbase 132" (11 feet) / 3,352 mm
Maximum underclearance 80" (6.7 feet) / 2,032 mm
Top Safety Lock 81" (6.9 feet) / 2,057 mm
Ramp height 2" / 50.75 mm
Rise/Lower Speed 55 seconds / 35 seconds
Motor
• 220 VAC at 50 Hz, 208-230 VAC at 60 Hz, 1 Ph
• 380 VAC at 50 Hz, 3 Ph
• 110 VAC at 50/60Hz, 1 Ph
If you have a Multi-Lift setup, see Multi-Autostacker for modified specifications.
