OPTIONAL EQUIPMENT INSTALLATION
30
5174010 HDS-18E; 27; 35; 37 AIR LINE KIT
Part # Description Qty.
5550502 1/ 4 Bulkhead Female Straight 3/ 8
Tube
3
5550503 3/ 8 Tube Male Elbow 90° 1/ 4 NPT 3
5550504 1/ 4 Male Run Tee 3/ 8 Tube #PST 1
5570784 Ø3/ 8 x 10ft Long Poly Tube Coil Hose 2
5570725 Ø10mm Poly Flow Tube 290”
5174011 HDS-27X; 35X; 37X AIR LINE KIT
Part # Description Qty.
5550502 1/ 4 Bulkhead Female Straight 3/ 8
Tube
3
5550503 3/ 8 Tube Male Elbow 90° 1/ 4 NPT 3
5550504 1/ 4 Male Run Tee 3/ 8 Tube #PST 1
5570784 Ø3/ 8 x 10ft Long Poly Tube Coil Hose 2
5570725 Ø10mm Poly Flow Tube 340”
Rolling Jack maximum weight capacity for use with
HDS-18E is 9,000 lb (4,082 kg) per unit
HDS-27 or HDS-27X is 13,500 lb (6,124 kg) per unit
HDS-35 or HDS-35X is 17,500 lb (7,938 kg) per unit
