BendPak HDS-40X - Assembly View; Description of Parts

8
When removing the lift from shipping angles pay close attention as the posts
can slide and can cause injury. Prior to removing the bolts make sure the
posts are held securely by a fork lift or some other heavy lifting device.
Rear Crosstube
Powerside Runway
Column with Power
Unit Mounting Bracket
Small Window
(2 Pulleys)
Front Crosstube
Offside Runway
Approach
Ramps
Large Window
(4 Pulleys)
Assembly View
HDS-18 / -27 / -35 / -37 / -40
