STEP 13
(Power-Unit Hook Up)
1. Have a certified electrician run the power supply to
motor. Refer to the data plate found on the motor for
proper power supply and wire size.
2. The power console comes available in either 110 volt
or 220 volt operation. REFER TO THE DATA PLATE
BEFORE CONNECTING POWER. Have a certified electri-
cian run either 110 volts or 208 - 230 volt single phase 60
HZ power supply to motor. (If you ordered optional three
phase power or 50HZ, refer to the data plate found on the
motor for proper power supply.) Be sure to size wire for a
25 amp circuit.
IMPORTANT POWER-UNIT
INSTALLATION NOTES
DO NOT run power unit with no oil. Damage to pump can
occur.
The power unit must be kept dry. Damage to power unit
caused by water or other liquids such as detergents, acid
etc., is not covered under warranty.
Improper electrical hook-up can damage motor and will not
be covered under warranty.
Motor can not run on 50HZ without a physical change in
motor.
Use a separate breaker for each power unit.
Protect each circuit with time delay fuse or circuit breaker.
For 208-230 volt, single phase, use a 25 amp fuse.
For 208-230 volt, three phase, use a 20 amp fuse.
For 380-440 volt, three phase, use a 15 amp fuse.
DO NOT attempt to raise vehicle until a
thorough operation check has been completed.
15
IMPORTANT NOTE:
DO NOT USE 110 VOLT POWER SUPPLY
for this power unit damage to motor will occur
which is not covered under warranty. You must
use a separate circuit breaker for each lift.
RISK OF EXPLOSION!
This equipment has internal arcing or parts that
may spark and should not be exposed to
flammable vapors. Motor should not be located in
a recessed area or below floor level.
NEVER expose motor to rain or other damp
environments.
DAMAGE TO MOTOR CAUSED BY WATER IS
NOT COVERED UNDER WARRANTY.
All wiring must be performed
by a certified electrician only.
DANGER!
DO NOT PERFORM ANY MAINTENANCE OR
INSTALLATION OF ANY COMPONENTS WITH OUT
FIRST ENSURING THAT ELECTRICAL POWER HAS
BEEN DISCONNECTED AT THE SOURCE OR PANEL
AND CANNOT BE RE-ENERGIZED UNTIL ALL
MAINTENANCE AND/OR INSTALLATION
PROCEDURES ARE COMPLETED.
