BendPak XPR-10A Service Manual

2-Post Lifts Product Decal Positioning
A
B
BPK Post Lift Decal.pdf
Material: Clear Adhesive PET
Size: 4.25”W x 38”H
Thickness: 4 Mil
Finish: Polished
Ink: U.V. protected, Opaque White
Print Process: Silk Screen, 85 line-screen (Yellow
color in file represents what should be clear PET
material and SHOULD NOT print as Yellow ink.
White area in file represents Opaque White ink.)
Lamination: Clear-gloss over-laminate for abrasion,
chemical, and ultra violet protection
PN 5905311
PN 5905555
*Place on back of Powerside Post.
2-Post Safety Decal.pdf:
Size: 4”W x 28.75”H
Material: White Vinyl Pressure Sensitive
Adhesive
Thickness: 4 Mil
Ink: U.V. protected CMYK 2/C Process
Finish: Polished
Print Process: Offset Lithography - 200 line-
screen or 300 p.p.i. for digital
Lamination: Clear-gloss over-laminate
for abrasion, chemical, and ultra violet
protection
Danger
Warning
Long wheelbase vehicles can damage lift
and/or cause personal harm or injury to
operators if loaded incorrectly.
All vehicles MUST be positioned on lift with
CENTER OF GRAVITY midway between adapters.
Failure to read, understand and
follow these instructions may
cause death or serious injury. Read
and understand these instructions
before using lift.
WIRE ROPE INSPECTION AND MAINTENANCE
• Liftingcablesshouldbereplacedevery(3)threeyearsor
 whenvisiblesignsofdamageareapparent.DONOTUSE
 LIFTWITHDEFECTIVEORWORNCABLES.
• Wireropeshouldbemaintainedinawell-lubricated
 conditionatalltimes.Wireropeisonlyfullyprotectedwhen
 eachwirestrandislubricatedbothinternalandexternal.
 Excessivewearwillshortenthelifeofthewirerope.The
 factorysuggestswireropelubricantthatpenetratestothe
 coreoftheropeandprovideslong-termlubricationbetween
 eachindividualstrand.Inordertomakesurethattheinner
 layersoftheroperemainwelllubricated,lubricationshould
 becarriedoutatintervalsnotexceedingthree(3)months
 duringoperation.
• Allsheavesandguiderollersincontactwiththemoving
 wireropeshouldbegivenregularvisualchecksforsurface
 wearandlubricatedtomakesurethattheyrunfreely.This
 operationshouldbecarriedoutatappropriateintervals
 generallynotexceedingthree(3)monthsduringoperation.
 Forallsheaveaxles,thefactoryrecommendsstandard
 wheelbearinggrease.Forallsheavesand/orguide
rollers,
 thefactoryrecommends90-WTgearoilorsimilarheavy
 lubricantappliedbyanymethodincludingpump/spray
 dispensing,brush,handand/orswabbing.
NEVER LIFT ANY VEHICLE IN ANY MANNER WITH LESS
THAN FOUR (4) ARMS. RATED CAPACITY OF EACH
LIFT ARM IS NO GREATER THAN ONE FOURTH (1/4)
OF THE OVERALL LIFTING CAPACITY.
IMPORTANT
OPERATION / MAINTENANCE
INSTRUCTIONS - PLEASE READ
TO RAISE LIFT
3ReadOperatingandSafetymanualsbeforeusinglift.
3Alwaysliftvehicleaccordingtomanufacturer’srecommended
 liftingpoints.
3Positionvehiclebetweencolumns.Adjustswingarmssothat
 vehicleispositionedwiththecenterofgravitymidway
 betweenpads.
3Positionliftcontactpadsatmanufacturersrecommended
 liftingpoints.
3Usetruckadaptersasneeded.Neverexceed9”ofpad/adapter
 height.
3RaiseliftbypressingRAISEBUTTONonpowerunituntilcontact
 padsmakecontactwiththeundersideofthevehicle.
3Rechecktomakesurevehicleissecure.
3Raisevehicletodesiredworkingheightthenpresspowerunit
 LOWERINGHANDLEuntilliftcarriagesrestontonearestsafety
 lockposition.
3Maintainvisualcontactwithvehicleandsurroundingareaatall
 timeswhileraisinglift.
3STOP IMMEDIATELYifloadshiftsorbecomesunlevel.
3Alwaysensuresafetylocksareengagedbeforeanyattemptis
 madetoworkonornearvehicle.
3Alwaysensureliftcontactpadsaremakingfullcontactwithvehicle
 beforeanyattemptismadetoworkonornearvehicle.
TO LOWER LIFT
3RaiseliftbypressingRAISEBUTTONonpowerunit.Elevateliftat
 leasttwoinchestoallowadequateclearanceforthelockstoclear.
3ClearsafetylocksbymaintainingpressureonSAFETYLOCK
 RELEASEHANDLEtoitsfurthesttravel.
3Besuretooltrays,standsorpersonnelareremovedfrom
 undervehicle.
3Lowervehiclebypressingpowerunitloweringhandleuntillifthas
 descendedcompletely.
3Maintainvisualcontactwithvehicleandsurroundingareaatall
 timeswhileloweringlift.
3STOP IMMEDIATELYifloadshiftsorbecomesunlevel.
3Beforeremovingvehiclefromliftarea,positionliftarmstoprovide
 unobstructedexit.
3NEVER,driveoverliftarms.
REQUIRED MONTHLY MAINTENANCE
3ALWAYSconsultoperationmanualforfactoryrecommended
 maintenance.
3Checkarmrestraintsforproperoperation.
3Checkallchain/cableconnections,boltsandpinstoinsure
 propermounting.
3Visuallyinspectsafetylocksforproperoperation.
3Visuallyinspectconcreteoor.DONOTUSELIFTifconcrete
 foundationshowssignsofdeterioration.
3Inspectallanchorboltsandretightenifnecessary.
3Checkcolumnsforsquarenessandplumb.
3Inspectallpivotpinsmakingsuretheyareproperlysecured.
3Checkequalizercabletension–cablesmusthaveequaltension-
 adjustifnecessary.
3Inspectallliftpads,replaceifnecessary.
3Ifliftisequippedwithoverheadcut-offswitch,checkfor
 properoperation.
WARNING!
1. WARNING:Ifcementanchorboltsareloose,oranycomponentof
 theliftisfoundtobedefective,DO NOT USE LIFT!
2. Neveroperatetheliftwithanypersonorequipmentbelow.
3. Neverexceedratedcapacity.
4. Alwaysinsuresafetylocksareengagedbeforeanyattemptismade
 toworkonornearvehicle.
5. Neverleaveliftinanelevatedpositionunlessthesafetylocks
 areengaged.
6. Donotpermitelectricmotortogetwet!Motordamagecausedby
 dampnessisnotcoveredunderwarranty.
CAUTION
BendPak, Inc.
®
P/N 5905555
USe PrOPer aDaPTerS
Do not attempt to lift trucks or other frame type vehicles
with standard at contact pads. Frame cradle contact pads
are recommended for use when lifting trucks, vans, or other
frame vehicles. NEVER use lift with missing or damaged
rubber pads. ALWAYS REPLACE rubber contact pads
when worn or damaged. Contact BendPak or your
BendPak dealer for product information.
FRAME CRADLE
CONTACT PADS
Danger
SKU# 5215506
P/N 5905311
1645 Lemonwood Drive
Santa Paula, CA 93060
U.S.A.
(805) 933-9970
www.bendpak.com
