DIMENSIONS ARE IN MM
☺
3
4
1
2
REVISION
REV
DESCRIPTION
EDITED BY
A
PRODUCTION RELEASE, DERIVERD FROM XPR-10C
02/16/2010
00293
B
UPDATED BOM REVISIONS
04/15/2010
00346
ITEM
PART
NUMBER
DESCRIPTION
1
5245133
XPR-10C LIFT SUPERSTRUCTURE
1
B
2
5250233
XPR-10C PARTS BOX
1
B
3
5210170
XPR-9F/FD/FS/ 10C/AC LOW PROFILE TRIPLE
TELESCOPING ARM ASSEMBLY
2
A
4
5215195
XPR-9/10C/CX LOW PROFILE MEDIUM ARM ASSEMBLY
2
A
SHEET 1 OF 2
DWG. NO.
A
TITLE:
CHECKED
DRAWN
SIZE:
MATERIAL:
B
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED
.
5260139
XPR-10C RECEIVED LIFT
02/16/2010
DO NOT SCALE DRAWING
SCALE:
THIRD ANGLE PROJECTION
04/30/2010
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING
