5. Maintain And Warranty
1). Maintain
(1). Battery replacement
A).When low battery icon is showed, please replace the
batteries.
(A). Press to turn off.
(B). Open the battery door properly.
(C). Replace the low power batteries by new batteries.
B). When the gauge is not use for long period, please take
out the batteries.
2). Protection of transducer
Because the wear face of transducer is propylene mate-
rial which easy to be scratched. During taking measure-
ment on rough material, please using the transducer in
gentle motion. The temperature of the hardware should
not over 60℃, otherwise it will cause damage on the tra-
nsducer. Adhering oil, dust on the wear face will speed
up aging of transducer and lead to rupture. Clean the lead
-wire & transducer after use.
3). Cleaning the cabinet
Do not use solvent/alcohol for cleaning which erode the
cabinet & LCD window, brush and sweep only with a mo-
ist cotton cloth.
4). Cleaning the sample block
Because of coupling agent should be put on the sample
block during calibration, after use the sample block sho-
uld be cleaned for preventing rust. In higher temperature
environment, be sure protect the block form the droplet of
water. If the gauge is not use for a long period, please
apply some antirust on the sample block.
5). Avoid shocking/impact. Do not store the unit in high
humidity environment.
LED
2. Warranty:
1).When the tolerance is over than stated in this manual,
please refer to the 3, 4, 5 chapter, in this manual.
2). Please contact us or distributor if the following occurs:
A. Component being destroyed, enable to measure.
B. Abnormal LCD display.
C. The tolerance is too big in proper operation.
D. Malfunction of keypad.
3). This gauge is a advanced technology product, the
repairing only by technician authorized by us, do not
try any alterations or repair attempts.
4). Warranty policy:
Please fill the warranty card with your cachet/chop after
purchasing this products, the warranty period for rep-
aired is 12 months form the date of original purchase.
During warranty period, product must be returned with
the invoice(copy) and warranty card to our customer
service department. The product will not be warranted
which without the warranty card.
Over warranty period, any repairing / maintenance will
charge the fee on the buyer in standard rate by local
distributor. The standard rate is not including the acc-
essories which not packing in standard package(For
example, abnormity transducer, lengthen lead-wire,
special software) .
We disclaims any liability due to: transportation dama-
ges; incorrect use or operation; manipulation, alterati-
ons or repair attempts; without warranty card, invoice.
5). Non-warranty list:
LCD, battery, probe, sample block, plastic case,
coupling agent
