T
o remov
e scan transmissional assembly:
1. R
emove 4 screws
2. Place trimmer on the pulley
3. W
e can remove scan tr
ansmissional assembly
Figure 7-3 Remove Scan Transmissional Assembly 1/2
7-4 API
Confidential
Maintenance
No Copy/Reproduction allowed
43
45
