Serial communication control 45
Pan_tiltDrive Up 8x 01 06 01 VV WW 03
01 FF
VV: Pan speed
0x01 (low speed)
to 0x18 (high
speed)
WW: Tilt speed
0x01 (low speed)
to 0x14 (high
speed)
YYYY: Pan
Position
ZZZZ: Tilt
Position
Down 8x 01 06 01 VV WW 03
02 FF
Left 8x 01 06 01 VV WW 01
03 FF
Right 8x 01 06 01 VV WW 02
03 FF
Upleft 8x 01 06 01 VV WW 01
01 FF
Upright 8x 01 06 01 VV WW 02
01 FF
DownLeft 8x 01 06 01 VV WW 01
02 FF
DownRight 8x 01 06 01 VV WW 02
02 FF
Stop 8x 01 06 01 VV WW 03
03 FF
Pan_tiltDrive Absolute Position 8x 01 06 02 VV WW
0Y 0Y 0Y 0Y 0Z 0Z 0Z
0Z FF
VV: Pan speed
0x01 (low speed)
to 0x18 (high
speed)
WW: Tilt speed
0x01 (low speed)
to 0x14 (high
speed)
YYYY: Pan
Position
ZZZZ: Tilt
Position
Relative Position 8x 01 06 03 VV WW
0Y 0Y 0Y 0Y 0Z 0Z 0Z
0Z FF
Home 8x 01 06 04 FF
Reset 8x 01 06 05 FF
Pan-tiltLimitSet Set 8x 01 06 07 00 0W
0Y 0Y 0Y 0Y 0Z 0Z 0Z
0Z FF
W:1 UpRight
0:DownLeft
YYYY: Pan Limit
Position (TBD)
ZZZZ: Tilt Limit
Position (TBD)
Clear 8x 01 06 07 01 0W
07 0F 0F 0F 07 0F 0F 0F
FF
Command Function Command packet Note
