Product information 55
Input/Output
Interface
Video interfaces
HDMI, LAN (POE), USB3.0 (Type B compatible
USB2.0), SDI, A-IN, RS232-IN, RS232-OUT,
RS422 (compatible with RS485), Dial Code,
Power Switch
Video output HDMI, SDI, LAN, USB3.0
Video stream Dual stream output
Video compression format
LAN Interface: H.265, H.264,
Dual stream output
USB3.0 Interface: YUY2, MJPEG, H.264, NV12,
H.265, Dual stream output
Audio input interface Double track 3.5mm linear input
Audio output interface HDMI, SDI, LAN, USB3.0
Audio compression format AAC
Network protocol
RTSP, RTMP, ONVIF, GB/T28181, VISCA
OVER IP, IP VISCA, RTMPS, SRT
Support remote upgrade, remote restart, remote
reset
Control interface RS232, RS422, RS485
Control protocol
VISCA/Pelco-D/Pelco-P, Baud Rate: 115200/
9600/4800/2400bps
Power interface HEC3800 outlet (DC12V)
Input voltage DC12V
Input electric current Maximum: 1.5A
Power consumption Maximum: 18W
PTZ
Parameter
Pan/Tilt rotation ±170°, -30°~ +90°
Pan control speed 0.1-100°/sec
Tilt control speed 0.1-45°/sec
Preset speed Pan: 100° sec, Tilt: 30° sec
Preset number 255 presets (10 presets by remote control)
Other
Parameter
Stored temperature
-10
o
C ~ 60
o
C
Storage humidity 20%~95%
Working temperature
-10
o
C ~ 45
o
C
Working humidity 20% ~ 80%
Dimension 178mm x 115.5mm x 150.9mm
Weight 1.38KG
Attachment
Package
12V/1.5A Power supply, RS232 control cable,
USB3.0 cable, Remote Control
Accessories optional Mounting (optional)
