(3) Support Timings:
Video mode
Horizontal
frequency
(KHz)
V
ertical
frequency
(Hz)
Sub-carrier
Frequency
(MHz)
NTSC 15.73 60 3.58
PAL 15.63 50 4.43
SECAM 15.63 50 4.25 or 4.41
PAL-M 15.73 60 3.58
PAL-N 15.63 50 3.58
PAL-60 15.73 60 4.43
NTSC4.43 15.73 60 4.43
2.1.3 Component Video Input
(1) Pin definition { RGB DB-15 x 1 (Female Type) }
1
5
6
10
11
15
(2) Signal Level:
Pin Si
g
nal Parameter Min T
y
pe Ma
x
1
Pr DATA
Pb DATA
Impedance 75 Ohm
3
Black pedestal 0 Volts
2 Y DATA_SOG
Impedance 75 Ohm
Amplitude 1 Volts peak-to-peak
Video amplitude 0.7 Volts peak-to-peak
Sync amplitude 0.3 Volts peak-to-peak
Black pedestal 0 Volts
6 Red GND
7 Green GND
8 Blue GND
(3) Support Timings:
Timing Resolution
Horizontal
frequency (KHz)
Vertical frequency
(Hz)
Dot Clock Frequency
(MHz)
Support?
480i 720 x 480 15.73 59.94 13.5
Y
480p 720 x 480 31.47 59.94 27
Y
576i 720 x 576 15.63 50 13.5
Y
576p 720 x 576 31.25 50 27
Y
720/50p 1280 x 720 37.5 50 74.25
Y
720/60p 1280 x 720 45.00 60 74.25
Y
1080/50i 1920 x 1080 28.13 50 74.25
Y
1080/60i 1920 x 1080 33.75 60 74.25
Y
1080/24P 1920 x 1080 27.00 24 74.25
Y
1080/25P 1920 x 1080 28.125 25 74.25
Y
1080/30P 1920 x 1080 33.75 30 74.25
Y
1080/50P 1920 x 1080 56.25 50 148.5
Y
1080/60P 1920 x 1080 67.5 60 148.5
Y
2.1.4 HDMI/DVI Input
- HDMI 1.3 Compliance
