16
(3) Support PC Timings:
Resolution Mode Refresh rate (Hz) H-frequency (kHz)
Clock (MHz)
640 x 480
VGA_60 59.940 31.469 25.175
VGA_72 72.809 37.861 31.500
VGA_75 75.000 37.500 31.500
VGA_85 85.008 43.269 36.000
VGA_120 119.518 61.910 52.500
720 x 400 VGA_70 70.087 31.469 28.3221
800 x 600
SVGA_56 56.250 35.156 36.000
SVGA_60 60.317 37.879 40.000
SVGA_72 72.188 48.077 50.000
SVGA_75 75.000 46.875 49.500
SVGA_85 85.061 53.674 56.250
SVGA_120 119.854 77.425 83.000
1024 x 768
XGA_60 60.004 48.363 65.000
XGA_70 70.069 56.476 75.000
XGA_75 75.029 60.023 78.750
XGA_85 84.997 68.667 94.500
XGA_120 119.989 97.551 115.5
1152 x 864 1152 x 864_75 75.00 67.500 108.000
1280 x 768
1280 x 768_60 60 47.396 68.25
1280 x 768_60 59.870 47.776 79.5
1280 x 768_75 74.893 60.289 102.25
1280 x 768_85 84.837 68.633 117.50
1280 x 800
WXGA_60 59.810 49.702 83.500
WXGA_75 74.934 62.795 106.500
WXGA_85 84.880 71.554 122.500
1280 x 1024
SXGA_60 60.020 63.981 108.000
SXGA_75 75.025 79.976 135.000
SXGA_85 85.024 91.146 157.500
1280 x 960
1280 x 960_60 60.000 60.000 108
1280 x 960_85 85.002 85.938 148.500
1360 x 768 1360 x 768_60 60.015 47.712 85.500
1440 x 900
WXGA+_60 60 55.469 88.75
WXGA+_60 59.887 55.935 106.500
WXGA+_75 74.984 70.635 136.75
WXGA+_85 84.842 80.430 157.000
1400X1050 SXGA+_60 59.978 65.317 121.750
1600x1200 UXGA 60.000 75.000 162.000
1680 x 1050 1680x1050_60
59.883 64.674 119.000
59.954 65.290 146.250
1920 x 1200 1920x1200_60 59.950 74.038 154.000
640x480@67Hz MAC13 66.667 35.000 30.240
832x624@75Hz MAC16 74.546 49.722 57.280
1024x768@75Hz MAC19 75.020 60.241 80.000
1152x870@75Hz MAC21 75.06 68.68 100.00
1024x576@60Hz Notebook Timing
60.00 35.820 46.996
1024x600@65Hz Notebook Timing
64.995 41.467 51.419
