18
(2) Support PC Timings:
Resolution Mode Refresh rate (Hz) H-frequency (kHz) Clock (MHz)
640 x 480
VGA_60 59.940 31.469 25.175
VGA_72 72.809 37.861 31.500
VGA_75 75.000 37.500 31.500
VGA_85 85.008 43.269 36.000
720 x 400 VGA_70 70.087 31.469 28.3221
800 x 600
SVGA_60 60.317 37.879 40.000
SVGA_72 72.188 48.077 50.000
SVGA_75 75.000 46.875 49.500
SVGA_85 85.061 53.674 56.250
1024 x 768
XGA_60 60.004 48.363 65.000
XGA_70 70.069 56.476 75.000
XGA_75 75.029 60.023 78.750
XGA_85 84.997 68.667 94.500
1024 x 576 BenQ 60.0 35.820 46.966
1024 x 600 BenQ 64.995 41.467 51.419
1280 x 800
WXGA_60 59.810 49.702 83.500
WXGA_75 74.934 62.795 106.500
WXGA_85 84.880 71.554 122.500
1280 x 1024
SXGA_60 60.020 63.981 108.000
SXGA_75 75.025 79.976 135.000
SXGA_85 85.024 91.146 157.500
1280 x 960
1280 x 960_60 60.000 60.000 108
1280 x 960_85 85.002 85.938 148.500
1440 x 900
W
XGA+_60 59.887 55.935 106.500
1400X1050 SXGA+_60 59.978 65.317 121.750
1600x1200 UXGA 60.000 75.000 162.000
640x480@67Hz MAC13 66.667 35.000 30.240
832x624@75Hz MAC16 74.546 49.722 57.280
1024x768@75Hz MAC19 75.020 60.241 80.000
1152x870@75Hz MAC21 75.06 68.68 100.00
640 x 480 VGA_120 119.518 61.910 52.500
800 x 600 SVGA_120 119.854 77.425 83.000
1024 x 768 XGA_120 119.804 98.958 137.750
(3) Support Video Timings (Component-2):
Timing Resolution
Horizontal
frequency (KHz)
Vertical frequency
(Hz)
Dot Clock
Frequency
(MHz)
Support?
480i 720 x 480 15.734/ 15.75 59.94/ 60 13.5
Y
480p 720 x 480 31.469/ 31.5 59.94/ 60 27
Y
576i 720 x 576 15.625 50 13.5
Y
576p 720 x 576 31.25 50 27
Y
720/50p 1280 x 720 37.5 50 74.25
Y
720/60p 1280 x 720 44.955/ 45 59.939/ 60 74.175/ 74.25
Y
1080/50i 1920 x 1080 28.125 50 74.25
Y
1080/60i 1920 x 1080 33.716/ 33.75 59.939 / 60 74.175/ 74.25
Y
1080/24P 1920 x 1080 27.00 24 74.25
Y
1080/25P 1920 x 1080 28.125 25 74.25
Y
1080/30P 1920 x 1080 33.75 30 74.25
Y
1080/50P 1920 x 1080 56.25 50 148.5
Y
1080/60P 1920 x 1080 67.432/ 67.5 59.939 / 60 148.35/ 148.5
Y
