Fig. 7-3 Fig. 7-4
7.5 Assemble “CW Module” to “DMD HSG” and lock with screws well (Fig.7-4).
Fig.7-4
Press Heatsink when
assemble spring screw
Fixed shafts of
DMD HSG
Scre
w
Gasket
○1
○2
○3
○4
