Introduction10
Projector exterior view
1. External control panel
(See "Projector" on page 12 for
details.)
2. Lamp cover
3. Focus ring (MX766/MW767)
Focus slide lever (MX822ST)
4. Projection lens
5. Lens cover
6. Vent (heated air exhaust)
7. Speaker
8. Zoom slide lever (MX766/MW767)
9. Front IR remote sensor
10. Quick-release button
Front/upper side
(MX766/MW767)
9
8
1
2
4
6
10
5
3
7
(MX822ST)
9
3
1
2
4
6
5
7
10
