47 Navigating the main menu
PIP Sets the PIP mode. Pictures from two independent video
sources are displayed on the screen at the same time.
The audio input is from the main source if the PIP mode is
activated.
Not available when HDR function is enabled.
Main Determines the main video source. Thunderbolt
3
•DisplayPort
HDMI1
HDMI2
Sub Determines the second video source for PIP
mode.
Thunderbolt
3
•DisplayPort
HDMI1
HDMI2
PIP Size Determines the size of the inset window in the
PIP mode.
Small
Medium
Large
PIP
Position
Adjusts the position of the inset window in the
PIP mode.
To p R i g h t
To p L e f t
Bottom Right
Bottom Left
PBP Sets the PBP mode to have two pictures displayed
side-by-side. Determines the video sources for the left and
the right windows respectively.
Not available when HDR function is enabled.
Left
Right
PBPx4 Sets the PBP mode to have four pictures displayed
side-by-side. Determines the video sources for four
windows respectively.
Not available when HDR function is enabled.
Top Left
To p R i g h t
Bottom Left
Bottom Right
SWAP Swaps the video screens.
•For PIP / PBP mode: the main and the sub sources will be
switched.
•For PBPx4 mode: the sources will be switched clockwise.
Item Function Range
