Preparation for Setup12
Mounting Touch Module
1. Attach the tape strip on the rear side of the PointWrite touch module.
2. Follow the instructions above to position the touch module on the
screen.
3M double tape (thickness: 1mm) is recommended.
3. Turn over the front cover.
4. Secure the touch module to the wall with screws.
5. Refer to page 17 to make sure the touch module is properly installed in
the center of the projection screen.
