Timing chart
The following table shows compatible signal types, their resolution and frequency refresh rates.
Horizontal: 15kHz, 31kHz to 90 kHz, Vertical: 50 Hz to 85 Hz
Mode Resolution H-Sync (KHz) V-Sync (Hz) Analog Digital
VGA 640x480
31.5 60 O O
37.9 72 O O
37.5 75 O
43.3 85 O O
SVGA 800x600
35.2 56 O O
37.9 60 O O
48.1 72 O O
46.9 75 O O
53.7 85 O
XGA 1024x768
48.4 60 O O
56.5 70 O O
60.0 75 O
68.7 85 O
WXGA
1280x720 45.0 60 O O
1280x768 47.8 60 O O
1280x800
49.7 60 O O
62.8 75 O
1360x768 47.7 60 O
1366x768 47.7 60 O
WXGA+ 1440x900 55.9 60 O
SXGA
1152x864 67.5 75 O
1280x960 60 60 O O
1280x1024
64.0 60 O O
80.0 75 O O
SXGA+ 1400x1050 65.3 60 O O
WSXGA+ 1680x1050 65.3 60 O
UXGA 1600x1200 75.0 60 O
VGA (MAC 13”) 640 x480 34.9 67 O
SVGA (MAC 16”) 832x624 49.7 75 O
XGA (MAC 19”) 1024x768 60.2 75 O
SXGA (MAC 21”) 1152x870 68.7 75 O
