BenQ W2000 - Page 61

61
Maintenance
*Supported timing for 3D signal with Frame Packing, Top-Bottom format, Side-by-Side, and Frame
Sequential format.
**Supported timing for 3D signal with Frame Packing, Top-Bottom format, and Side-by-Side format.
***Supported timing for 3D signal with Top-Bottom and Side-by-Side format.
****Supported timing for 3D signal with Frame Sequential format.
*****Supported timing for 3D signal with Side-by-Side format.
Supported timing for EDTV and HDTV (via Component inputs)
*Supported timing for 3D signal with Frame Sequential format.
Timing Resolution
Ver tical
Frequency
(Hz)
Horizontal
Frequency
(KHz)
Pixel
Frequency
(MHz)
Remark
480i**** 720 (1440) x 480 59.94 15.73 27 HDMI only
480p**** 720 x 480 59.94 31.47 27 HDMI only
576i 720 (1440) x 576 50 15.63 27 HDMI/DVI
576p 720 x 576 50 31.25 27 HDMI/DVI
720/50p** 1280 x 720 50 37.5 74.25 HDMI/DVI
720/60p* 1280 x 720 60 45.00 74.25 HDMI/DVI
1080/24P** 1920 x 1080 24 27 74.25 HDMI/DVI
1080/25P 1920 x 1080 25 28.13 74.25 HDMI/DVI
1080/30P 1920 x 1080 30 33.75 74.25 HDMI/DVI
1080/50i***** 1920 x 1080 50 28.13 74.25 HDMI/DVI
1080/60i***** 1920 x 1080 60 33.75 74.25 HDMI/DVI
1080/50P*** 1920 x 1080 50 56.25 148.5 HDMI/DVI
1080/60P*** 1920 x 1080 60 67.5 148.5 HDMI/DVI
Format Resolution Refresh rate (Hz) H. Freq. (KHz) Pixel Freq. (MHz)
480i* 720 x 480 59.94 15.73 13.5
480p* 720 x 480 59.94 31.47 27
576i 720 x 576 50 15.63 13.5
576p 720 x 576 50 31.25 27
720/50p 1280 x 720 50 37.5 74.25
720/60p* 1280 x 720 60 45.00 74.25
1080/50i 1920 x 1080 50 28.13 74.25
1080/60i 1920 x 1080 60 33.75 74.25
1080/24P 1920 x 1080 24 27 74.25
1080/25P 1920 x 1080 25 28.13 74.25
1080/30P 1920 x 1080 30 33.75 74.25
1080/50P 1920 x 1080 50 56.25 148.5
1080/60P 1920 x 1080 60 67.5 148.5
