BenQ W2000+ User Manual

W2000/W2000+
Digital Projector
Home Cinema Series
User Manual
V 1.00

BenQ W2000+ Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	- m
Vertical scan range	23 - 120 Hz
Horizontal scan range	15 - 102 kHz
Projection technology	DLP
Contrast ratio (typical)	15000:1
Screen size compatibility	30 - 300 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-30 - 30 °
RMS rated power	20 W
Number of built-in speakers	2
Supported 3D formats	Frame Sequential, Frame packing, Side by side, Top and bottom
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Analog signal format system	NTSC, PAL, SECAM
Lamp power	240 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	3500 h
Service life of light source (economic mode)	7000 h
Offset	105 %
Throw ratio	1.15 - 1.5:1
Focal length range	16.88 - 21.88 mm
Aperture range (F-F)	2.59 - 2.87
Vertical lens shift range	0 - 10 %
Placement	Desktop
Product type	Standard throw projector
Product color	Black
Market positioning	Home cinema
Noise level	29 dB
Preset modes	3D, Bright, Cinema, Custom, Game, ISF Day
Noise level (economic mode)	27 dB
On Screen Display (OSD) languages	ARA, BUL, CHI (SIMPL), CHI (TR), CRO, CZE, DAN, DEU, DUT, ENG, FIN, FRE, GRE, HUN, IND, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR
HDMI version	1.4a/2.0a
Serial interface type	RS-232
USB 2.0 ports quantity	3
S-Video inputs quantity	0
CardBus PCMCIA slot type	No
Wi-Fi	-
Optical disc player type	Not included
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	353 W
Operating temperature (T-T)	0 - 40 °C
Remote control type	IR

Weight and Dimensions

Depth	277 mm
Width	380.5 mm
Height	121.7 mm
Weight	3600 g

Summary

Overview of BenQ Projector Features

Projector Features

Details the projector's compatibility, picture quality, color reproduction, modes, inputs, and advanced features.

Shipping and Optional Accessories

Standard Accessories Included

Lists the items included in the box, noting regional variations for some accessories.

Optional Accessories Available

Highlights optional accessories available for purchase, such as wireless FHD kits.

Projector Exterior Views and Controls

Front and Upper Side View

Identifies all controls and ports located on the front and top surfaces of the projector.

Rear and Lower Side View

Details the connection ports and other features on the rear and lower sides of the projector.

Projector Controls and Functions

Control Panel Operation

Explains the function of each button on the projector's control panel for operation and menu navigation.

Remote Control Usage

Remote Control Functions

Details the purpose and operation of each button on the projector's remote control.

Remote Control Operation Details

Remote Control Battery Replacement

Provides step-by-step instructions for replacing the batteries in the projector's remote control.

Remote Control Effective Range

Explains the optimal distance and angle for using the remote control with the projector's IR sensor.

Projector Installation

Choosing an Installation Location

Guides users on selecting the best position for the projector based on screen size and equipment placement.

Obtaining Projected Image Size

Projection Dimensions Guide

Provides a table and illustration to help determine the correct projection distance for various screen sizes.

Vertical Lens Shift Adjustment

Connecting Equipment to the Projector

Connecting Video Equipment

Details methods for connecting various video source devices to the projector via different terminal types.

Connecting HDMI Devices

Explains how to connect HDMI-compatible devices for uncompressed video data transmission.

Smart Device Connectivity

Component Video Connection

Video and Computer Connections

Connecting Video Devices

Instructions for connecting composite video devices using a composite video cable.

Connecting a Computer via VGA

Details how to connect the projector to a computer using a VGA cable and laptop specific notes.

Wireless Full HD Kit Setup

Projector Operation and Setup

Starting Up the Projector

Guides on powering on the projector, initial setup wizard, and basic operational steps.

Projector Shutdown and Security Features

Shutting Down the Projector

Provides the correct procedure for powering off the projector and its cooling down process.

Utilizing the Password Function

Explains how to set up and manage password security to prevent unauthorized use of the projector.

Input Source Management

Selecting an Input Source

Details how to choose the active video source from the available connected inputs.

Renaming Input Sources

Describes how to customize the names of the input sources displayed on the selection bar.

Adjusting the Projected Image

Adjusting Projection Angle

Instructions on using the projector's feet to set the correct projection angle and height.

Auto-Adjusting the Image

Explains how to use the AUTO function for automatic picture optimization, primarily for PC signals.

Fine-Tuning Image Size and Clarity

Guides on using the zoom ring and focus ring to adjust the projected image size and sharpness.

Correcting Keystone Distortion

Menu Functions Overview

About the OSD Menus

Introduces the two types of On-Screen Display (OSD) menus: Basic and Advanced, for projector settings.

Using the Basic OSD Menu

Using the Advanced OSD Menu

Picture Menu Settings

Picture Mode Selection

Allows selection of preset picture modes (Bright, Vivid, Cinema, Game, 3D, User) for optimal viewing.

User Mode Management

Enables loading settings from presets or renaming custom picture modes for personalized use.

Audio Setup Menu

Sound Mode and EQ Configuration

Configure sound modes (Standard, Cinema, etc.) and personalize audio with User EQ settings.

Volume and Mute Control

Adjusts the projector's speaker volume and provides options for muting the audio output.

Display Menu Settings

Aspect Ratio Adjustment

Allows changing the display aspect ratio (Auto, 16:9, Wide, Letter Box) for different content types.

Wall Color Correction

Corrects projected picture color based on the projection surface color (e.g., yellow, pink, green, blue).

System Setup - Basic Menu

System Setup - Advanced Menu

Information Menu

Projector Maintenance Guide

General Care of the Projector

General advice on keeping the projector clean, especially the lens, and handling operations.

Cleaning the Projector Lens

Provides detailed instructions on safely cleaning the projector lens using appropriate materials and methods.

Cleaning the Projector Case

Guides on how to clean the projector's exterior case using soft cloths and mild detergents.

Storing the Projector

Recommends proper conditions and methods for storing the projector for extended periods.

Lamp Information and Life Extension

Getting to Know Lamp Hour

Explains how to check the cumulative operating hours of the projection lamp.

Extending Lamp Life

Provides settings like Economic or SmartEco modes to maximize the lifespan of the projection lamp.

Lamp Replacement and Auto-Off

Timing of Lamp Replacement

Details warning messages and indicators that signal the need to replace the projector lamp.

Setting Auto Off Function

Configures the projector to automatically turn off when no input signal is detected for a set period.

Replacing the Projector Lamp

Projector Indicator Lights and Status

Troubleshooting Common Issues

Projector Specifications

Optical Specifications

Details resolution, display system, lens parameters, and lamp wattage for the projector.

Electrical Specifications

Lists power supply requirements, voltage, frequency, and power consumption figures.

Mechanical and Connectivity

Covers projector weight, dimensions, output terminals (speaker, audio), and input terminals (HDMI, VGA, USB).

Environmental Requirements

Specifies operating and storage conditions including temperature, humidity, and altitude limits.

Dimensions and Mounting Information

Projector Dimensions

Provides the physical width, depth, and height measurements of the projector unit.

Ceiling Mount Installation Details

Details ceiling mounting requirements, including screw specifications and visual diagrams.

Supported PC Input Timings

Supported HDMI Input Timings

Supported EDTV and HDTV Timings

Supported Video Input Timings

Warranty and Legal Information

Warranty Terms and Conditions

Outlines BenQ's warranty policy, obligations, and conditions for product defects.

Copyright Notice and Restrictions

States the copyright ownership and usage restrictions for the user manual content.

Disclaimer Statement

Clarifies BenQ's limitations on representations and warranties regarding the manual's content.
