BENSHAW RediStart MX 2 SEP Series User Manual

RediStart MX
2
- SEP Synchronous Controller User Manual
16
Wire Gauge: The terminals can support 1–14 AWG wire or 2–16 AWG wires or smaller.
Torque Rating: The terminals on the control cards have a torque rating of 5.0-inch lb. or 0.56Nm.
This MUST be followed or damage will occur to the terminals.
NOTE: Refer to Control Card Layouts on Pages 29 and 30.
2.2.2 Measurements and Accuracies
Analog I/O
(Hall Effect
Input)
TB5
1: Ain Power
2: M
3: Common
4: Ground (Shield)
5: Aout
6: Common
7: Shield
Input:
Voltage or Current
Voltage: 0
– 10VDC, 67KΩ impedance
Current: 0
– 20mA, 500Ω impedance
Output:
Voltage or Current
Voltage: 0
– 10VDC, 120mA maximum
Current: 0
– 20mA, 500Ω load maximum
Display RJ45 — Door Mounted Display Connector
SCR J6 to J11
1: Gate
2: Cathode
SCR Gate Connections
Table 1: Terminals (Continued)
Function
Terminal
Block
Terminal Number Description
Table 2: Measurements and Accuracies
Internal Measurements
Hall Effect Input
Conversion: True RMS, Sampling @ 1.562kHz
Range: 1 – 1000A
Line Voltage Inputs
Conversion: True RMS, Sampling @ 1.562kHz
Range: 100 – 1,250VAC, 23 to 72 Hz
Metering
Current: 0 – 40,000 Amps ± 3%
Slip % 0.0 – 100%
Voltage: 0 – 1,250 Volts ± 3%
Line Frequency: 23 – 72 Hz ± 0.1 Hz
Run Time: ± 3 seconds per 24 hour period
Analog Input: Accuracy ± 3% of full scale (10 bit)
Analog Output: Accuracy ±2% of full scale (12 bit)
NOTE: Percent accuracy is percent of full scale of the given ranges, Current = Motor FLA,
Voltage = 8,000V, Watts/Volts-Amps/Watt-Hours = Motor & Voltage range
