1.15 Technical Details
Model 30 40 60 85
Heat Output (max)
kW/hr
Btu/hr
29.1
99,289
39.74
124,191
58.1
198,237
82.5
282.513
Heat Input (Gross)
kW/hr
Btu/hr
35.4
120,785
48.9
166,847
70.3
239,864
102.1
348,365
Heat Input (Nett)
kW/hr
Btu/hr
31.9
108,823
44.09
150.435
63.3
215,979
91.9
313,563
Nett Eciency
% 91.2 90.14 91.72 90.06
Burner Type
Riello GS5 GS5 GS10 GS10
Gas Connection
RC½ RC½ RC½ RC½
Fuel Consumption Nat Gas
m³/hr
ft³/hr
3.37
119
4.66
165
6.69
236
9.71
343
Burner Pressure Nat Gas
mbar
Ins WG
2.3
0.9
3.6
1.4
2.5
1.0
5.3
2.1
Min Gas Inlet Pressure Nat Gas
mbar 17. 5 17. 5 17. 5 17. 5
Head Setting Nat Gas (no ue)
Number 2.0 5.0 2.0 4.0
Air Setting Nat Gas (no ue)
Number 2.8 4.5 2.8 6.0
Fuel Consumption LPG
m³/hr
ft³/hr
l/h
1.3
46
4.9
1.78
63
6.7
2.56
91
9.7
3.7
131
14.0
Burner Pressure LPG
mbar
Ins WG
3.1
1.2
4.6
1.8
3.5
1.4
5.5
2.2
Min Gas Inlet Pressure LPG
mbar 37.0 37.0 37.0 37.0
Head Setting LPG (no ue)
Number 1 5 2 3.5
Air Setting LPG (no ue)
Number 2.5 4 2.8 4
Available Outlet Pressure
Pascals
Ins WG
75
0.3
100
0.4
144
0.6
105
0.4
Nozzle Discharge Velocity
m/sec
ft/min
5.73
1124
4.53
888
6.8
1339
6.88
1354
Air Throw (approx)
mtrs
ft
14
45
14
45
17.1
55
17.1
55
Air Delivery (std)
m³/sec
ft³/min
0.61
1300
0.71
1500
1.03
2180
1.39
2950
Temp Rise Through Heater
°C
°F
39
70
50.3
90
47.2
85
47.2
85
Combustion Chamber
mbar 0.21 0.21 0.24 0.34
Sound Level
dba 67 69 69 71
Flue Resistance
Min mbar
Max mbar
-0.2
0.6
-0.2
0.6
-0.2
0.6
-0.2
0.6
Flue Diameter
mm 125 125 150 175
Electrical Supply
Standard 230/1/50 230/1/50 230/1/50 230/1/50
Rated Input
kW 0.55 0.55 0.75 0.75
Fused Isolator Size
Amps 16 16 20 20
Running Current
Amps 3.2 4.8 7.9 8.5
Electrical Supply
Optional n/a n/a 415/3/50 415/3/50
Rated Input
kW n/a n/a 1.5 1.5
Fused Isolator Size
Amps n/a n/a 16 16
Running Current
Amps n/a n/a 2.2 2.2
Weight
kg 196 196 245 247
Nozzle Amount
no. 2 2 2 3
Nozzle top Plate Outlet Dia
Ø mm 242 242 242 242
Flue Temperature (Gross)
@ 20°C
Ambient
220 254 200 210
