Bentel Security FireClass 100 - Page 42

3.
Press the ↵ key to view the parameters of
the devices at the lowest address. If sev-
eral devices share the same address, de-
tectors will be shown first.
4. Position the cursor on the last parameter
on the bottom right then press the ↵ key.
5. The display will show the parameters of
the device at the next address.
6. Position the cursor on the first character of
the second line then press the ← key.
7. The display will show the parameters of
the device at the previous address.
8. Press ESC to step back to the CONNECTIONS menu (step 1.).
PRG:Smoke (Optic)%##
Device: SENSOR
Z=ØØ Z=ØØ Z=ØØ Z=ØØ
AT=5Ø **V=ØØ ** 1/Ø1
PRG:Smoke (Optic)%##
Device: SENSOR
Z=ØØ Z=ØØ Z=ØØ Z=ØØ
AT=5Ø **V=ØØ ** 1/Ø1
PRG:Smoke (Optic)%##
Device: SENSOR
Z=ØØ Z=ØØ Z=ØØ Z=ØØ
AT=5Ø **V=ØØ ** 1/Ø2
PRG:Smoke (Optic)%##
Device: SENSOR
Z=ØØ Z=ØØ Z=ØØ Z=ØØ
AT=5Ø **V=ØØ ** 1/Ø2
PRG:Smoke (Optic)%##
Device: SENSOR
Z=ØØ Z=ØØ Z=ØØ Z=ØØ
AT=5Ø **V=ØØ ** 1/Ø1
42 Analogue Fire Control Panel FireClass200
