Printer
A serial printer can be connected to the RS232 port of the control panel,
for real-time printout of events.
Select Printer from the SYSTEM menu
(press 7).
Select ON to enable or OFF to disable the
Printer.
Press the ↵ key to confirm, or ESC to exit without saving and step back to
the SYSTEM menu.
Verify
The Verify option from the PROGRAMMING menu is reserved for future
use.
If the Ver option is selected from the PRO-
GRAMMING menu (key 8).
The display will show ...
Press ESC to step back to the PROGRAMMING menu.
PRG: SYSTEM
1=Date/Time 2=Blink
3=Wire 4=SIL 5=WT
6=NET 7=Printer
PRG: SYSTEM
Condition
Printer
ENABLED :OFF
1=Auto 2=Devices
3=PassWD 4=MesINI
5=Zones 6=Opt 7=Sys
8=Ver 9=Def Ø=Tel
PRG: VERIFY
Future Use
Future Use
Future Use
PROGRAMMING 71
