To view the parameters of other devices on the same loop ---- work through
the steps in the "Auto learning" section. Press ESC to exit and go back to
step 2.
Conventional Line
Figure 21 shows the parameters of the Conventional Line (terminal [LC]).
Conventional Line programming is as per analogue detectors. Refer to the
"Programming: Fire detectors" section for the description of the parameters
shown in figure 17.
+
The Alarm threshold value is not valid for the Conventional Line, as the
connected detectors supply discrete values only (alarm, open/short-circuit).
Figure 21 Conventional Line parameters
PROGRAMMING 51
