Bentone B 80-3R - Technical Data B 80-3; Dimensions

7 Bentone
2. Technical data B 80-3
The burner is intended for:
• Light oil, B10 heating oil/biofuel blend (as defined in DIN V51603-6)
and is used for:
• Water heating generators
• Hot air generators
2.1 Dimensions
Dimensions are in mm
* Min. recommended distance to floor.
A Ø B Ø C D E F G H *I
B 80-3
396 260 205 730 408 504 472 867 200
B 80-3
696 260 205 730 408 504 472 867 200
165 305 06
G
H
A D
Ø B
Ø C
E
F
*I
