INST-TS1-V13
18/11/10
Page 2
Table of Contents
1. FEATURES ....................................................................................................... 3
2. SPECIFICATIONS ............................................................................................ 3
3. DIMENSIONS .................................................................................................... 4
4. MOUNTING AND INSTALLATION ................................................................... 5
5. WIRING ............................................................................................................. 9
6. PROGRAMMING AND SETUP ....................................................................... 10
7. PROBLEM SOLVING ..................................................................................... 10
8. FREQUENTLY ASKED QUESTIONS ............................................................ 11
Important TS1 Installation Issues
1. The sender must not be mounted closer than 150mm from the
centre of the sender to sides of the tank, baffles or other intrusions.
2. Only use on tanks greater than 200mm in depth.
3. Sender must be mounted parallel to the surface of the liquid.
4. Do not install on flexible tanks that may bulge/distort as fluid levels
change.
5. Check unit is calibrated to suit tank shape, depth and fluid type.
6. Make sure that sender protrusion is NOT in contact with any
object including sealants when mounted.
7. Use gasket and fittings as provided.
8. Mount above deepest point of the tank.
