5. Wiring
Power must be removed before TS1 is connected to the system. Ensure wiring is
correct or else damage may occur rendering the device inoperable.
+
-
NEG
BAR
POS
BAR
OUTPUT (GREEN)
POS (RED)
NEG (BLACK)
+
-
NEG
BAR
POS
BAR
OUTPUT (GREEN)
POS (RED)
NEG (BLACK)
G
12V 12V
USE 24V RATED GAUGES FOR 24V SYSTEMS
(GAUGE SHOULD HAVE DROPPING RESISTOR)
(S)
