To open the bobbin cover, slide it against you.
Inserting the bobbin in the bobbin holder with the thread running
counter clockwise direction.
Pull the thread along the arrow marking through the slit under
the finger (A) as far as the pulley (B).
To make sure that the thread is pulled into the tension spring of
the bobbin holder, press a finger slightly onto the bobbin while
pulling. As a check you must feel a resistance in the thread feed.
Pull the thread at the arrow markings into the stitch plate thread
guide from (B) to (C).
To cut off excess thread pull thread back over the cutting off
blade at point (C).
To close the bobbin cover, push it to the back.
Attention:
- Turn power switch to "O" before threading or unthreading the
machine.
- The thread take-up lever must be in the highest position when
threading.
- A wrong threading in can cause damages to the machine!
Inserting the Bobbin
Machine Setup
13
