Getting ready to Embroider
10
Inserting the bobbin
Place the bobbin in the bobbin holder with the thread unwinding
counter-clockwise.
1. Thread
2. Bobbin holder
Guide the thread into front notch on the front of the bobbin holder.
Draw the thread to the left, sliding it between tension spring blades.
3. Front notch
Continue to draw the thread lightly until the thread slips into side
notch.
4. Side notch
Pull out about 10 cm (4") of thread to the rear.
Refer to the threading chart shown on the hook cover plate to
check the threading
Re-attach the hook cover plate.
5. Bobbin thread
6. Hook cover plate
7. Threading chart
1
2
3
4
7
5
6
