ENGLISH
Installation Instructions
4
,167$//$7,21127(6
I0
WARNING
CAUTION
TECHNICAL DATA
For cutout dimensions see followiing section titled:
Preparing location
Ovens Dimension Model
Electrical Ratings and Maximum Connected Load
@ 120/240 Volts 60 Hz @ 120/208 Volts 60 Hz
Amperes Watts Amperes Watts
SINGLE OVEN
multifunction
24” (60 cm) F24PROXV 13,3 3100 11,7 2350
Ltr. DIMENSION 24”
A Cutout Width
22 1/16”
(56 cm)
B Cutout Depth
24”
(61 cm)
C Cutout Height
23”
(58,5 cm)
D Floor Bottom of Cutout
34”
(86,5 cm)
E Minumum Spacing
1/2”
(1,3 cm)
F Cutout Width
23 13/16”
(60,5 cm)
G Cutout Height
23 3/8”
(59,4 cm)
H
Visible part of the mounting strips
3/4”
(1,9 cm)
