53
EN
SIDE BY SIDE CONFIGURATION INSTALLATION
• All freezer columns include one connection trim kit (CTXV).
CABINET CUTOUT DIMENSIONS
Please check cabinet cutout dimensions below before starting the installation.
Configuration 18+24 18+30 24+24 24+30 30+30
“A” Dimension 42” (1066mm) 48” (1219mm) 48” (1219mm) 54” (1371mm) 60” (1524mm)
