54
LOCATION OF THE ELECTRICAL WIRING
Location of the electrical wiring must be within the range given below.
ATTENTION:
Do not use extension cables or two-pin adaptors and do not remove the ground terminal of the
grounding cable.
ATTENTION:
A qualified electrician must ensure that the poles of the socket are connected correctly. Verify that
the grounding of the socket is correct.
Configuration 18+24 18+30 24+24 24+30 30+30
“A” Dimension 13” (330mm) 19” (482mm) 13” (330mm) 19” (482mm) 19” (482mm)
3. INSTALLATION INSTRUCTIONS
