LaserSpeed 8000/9000 I/O Module Instruction Handbook
Operation
Part No. 93342 / Drawing No. 0921-01516 Page 62 of 84 Revision E (Dec 2013)
Material Present Light
When lit, indicates that material is present in front of
the LaserSpeed. ONLY USED WITH
LS9000/LS8000-2 GAUGES.
Laser at Temperature Light
When lit, indicates that laser is at operational
temperature.
Laser Power Light
When lit, indicates that power is applied to the laser
diode.
Shutter Open Light
When lit, indicates that the laser gauge’s shutter is
open.
Note that all indicators are blank when there is no communication from the
LaserSpeed gauge.
Profibus Operation
The Profibus module is automatically detected.
Status indications are described in the LaserSpeed I/O Module Operator Guide.
Profibus Command Structure
Values are updated every time the LS9000/LS8000 is updated.
The Status/Command, Velocity, Length, Quality Factor, and Status information is
updated at the User update
Use 93434 I/O Module hms1003.gds file for setting up the profibus. This is
supplied on a CD with the I/O Module.
Rate specified by the LS9000/LS8000.
Note: When sending configuration parameters to the LS9000/LS8000, the
status, velocity and length transmission from the gauge is temporarily halted
while the LS9000/LS8000 is updating its configuration parameters. This will
interrupt data being output via the Ethernet, Profibus, Serial and Parallel I/O
ports.
PUV – Status Command Word
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit2
Bit 1
Bit 0
0
0
0
0
0
0
Retrieves data
from
LaserSpeed
Send Data to
LaserSpeed
