LaserSpeed 8000/9000 I/O Module Instruction Handbook
Installation
Part No. 93342 / Drawing No. 0921-01516 Page 16 of 84 Revision E (Dec 2013)
Parallel Outputs
There are three, 37-pin D-Subminiature, Parallel output ports:
Outputs the system status and accepts control inputs
Outputs either Length from the gauge or Elongation
Ratio that is Calculated in the I/O Module.
Outputs the Velocity measurement from the gauge
Status Signals
Status Signals (pins numbered 1–16) are generated as solid state closures. The
contacts close when the condition is true. The contact maximum voltage and
current ratings are: 200mA at 30 VAC/VDC for resistive loads.
System input signals (pins numbered 20–31) are optically-isolated input signals
between 5V
DC
and 30V
DC
. The input should be applied to the INPUT+ pin, and
ground should be applied to the INPUT– pin for each signal used. Refer to the
following table pin-out information.
