LaserSpeed 8000/9000 I/O Module Instruction Handbook
Installation
Part No. 93342 / Drawing No. 0921-01516 Page 9 of 84 Revision E (Dec 2013)
Light Stack
Output to drive a light stack. Outputs pull up to +24 volts.
Laser ON, Shutter is CLOSED
Laser ON, Shutter is OPEN
LaserSpeed Gauge
37 pin D connector for connection to the LaserSpeed gauge
cable. This connector is compatible with all cables that have
part number 85277.
Passes signals from the DB25 connector on a
LS9000/LS8000. The pinout of this connector is compatible
with 25-pin LaserSpeed breakout boxes. Signal descriptions
are listed in a table below.
Pass-through connector for the LS9000/LS8000 gauge’s
optional Ethernet connection that provides a direct
connection to the gauge over Ethernet. If the attached
gauge does not have the Ethernet option installed, then this
connector is not used.
Pass-through connector for the LS9000/LS8000 gauge’s RS-
232 serial port. This connector can be connected to a PC
using a straight-through DB9 serial cable. LaserTrak or a
terminal program can be used to communicate directly with
the gauge via this serial port.
