Then extract the paper filter using pliers. Check the condi-
tion of the O-ring too, and replace it if necessary.
Change the filter and refit the cover, tightening the three
M6x20 bolts to 10 Nm.
Refit the oil drainplug, tightening it to 20 Nm, and refill
with 0.9 litres of engine oil (BARDHAL XTC60 15W50).
Finally, tighten the oil filler plug (A) to 10 Nm.
BRAKE MASTER CYLINDER FLUID
Front brake
Use the sight-glass (A) to check the brake fluid level.
There must always be enough brake fluid for the level
to be visible in the sight-glass. If there is not enough, the
fluid must be brought up to the correct level. To do this,
refill the reservoir by unscrewing the two screws (B), re-
moving the filler cap (C) and topping up the fluid.
