Rear brake
Before you can check the rear brake fluid, you must first
remove the rear mudguard by unscrewing the seven re-
taining screws (four on the outside, one on the tank (A),
one securing the filter cover (B) and one inside the filter
box (C)). Then look through the brake fluid reservoir (E)
to check the fluid. The level must never fall below the
minimum level line marked on the reservoir (E). To top
up the level, remove the filler cap (F) and refill with brake
fluid.
Warning
If you notice softness in the lever, there could
be an air bubble in the system. In this case,
bleed the rear brake system.
Alternatively, contact your dealer immedi-
ately.
Note:
Change the fluids in accordance with the inter-
vals in the table on page 29, using the lubricants
recommended on page 13.
