GENERAL INFORMATION
CONOSCENZA DEL VEICOLO
Key
1 Ignition switch
2 Indicator warning light
3 Frame earth connection
4 Stand-down warning light
5 Headlight (12V-55/60W two-light bulb)
6 LH control set (horn button, dip switch, indicator
switch, high beam button)
7 LH front indicator (12V-10W bulb)
8 High beam warning light
9 Engine stop button
10 Battery (12V-9Ah)
11 LH rear indicator (12V-10W bulb)
12 Rear light (12V-5/21W bulb)
13 RH rear indicator (12V-10W bulb)
14 Dynamo
15 Spark plug
16 Electronic control unit
17 12V regulator
18 Neutral indicator
19 RH front indicator (12V-10W bulb)
20 12V HORN
21 Neutral sensor
22 Wheel revolution sensor
ELECTRICAL DIAGRAM
23 Front brake light button
24 RH control set (start button, engine stop switch)
25 Stand relay
26 Engine earth connection
27 Side stand switch
28 Number plate light (12V-5W bulb)
29 10A fuse
30 Starter relay
31 Starter motor
32 4700 µ F-25V capacitor
33 HV coil
34 Flasher unit
35 Clutch button

Beta RR 125 series Specifications

General

Displacement	124.8 cc
Cooling System	Liquid cooled
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Ignition	Electronic
Transmission	6-speed
Front Tire	90/90-21
Lubrication	Wet sump
Clutch	Wet multi-disc
Final Drive	Chain
Front Suspension	41 mm upside-down fork
Rear Suspension	Monoshock
Front Brake	260 mm disc
Rear Brake	220 mm disc
