MAINTENANCE AND CHECKS
MANUTENZIONE E CONTROLLI
RIMOZIONE
SELLA PASSEGGERO E FILTRO ARIA
Per accedere al filtro è necessario
smontare la sella svitando la vite A
posta nella parte posteriore della
sella e sfilando la sella nel verso B
come indicato in figura, quindi pro-
cedere nel modo seguente:
- Estrarre il coperchio C sollevando
gli elastici D e sfilandolo dalla par-
te posteriore
B
A
D
C
REMOVING THE PASSENGER SEAT
AND THE AIR FILTER
To access the filter you must re-
move the saddle by unscrewing
screw A on the saddle top and push-
ing the saddle in direction B as shown
in the figure. After that, follow these
steps:
- Lift rubber bands D and remove
cover C by pulling it towards the
back of the vehicle.

Beta RR 125 series Specifications

General

Displacement	124.8 cc
Cooling System	Liquid cooled
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Ignition	Electronic
Transmission	6-speed
Front Tire	90/90-21
Lubrication	Wet sump
Clutch	Wet multi-disc
Final Drive	Chain
Front Suspension	41 mm upside-down fork
Rear Suspension	Monoshock
Front Brake	260 mm disc
Rear Brake	220 mm disc
